VPA

Features

Material: Steel or Aluminum

Available Thicknesses:

Steel: 22 gauge

Aluminum: 1.2 or 1.6 mm

Maximum Dimensions: 16.6875″ x 240″ (424 mm x 6096 mm)

Available Finishes:

Steel: WOOD-LIKE, STANDARD and CUSTOM (ask a representative for any other steel colour).

Aluminum: CUSTOM and ANODIZED

Product Description

The VPA panel consists of a steel or aluminum enclosure, painted to the customer's choice, and covers a 50 mm-thick Whispertone #6 acoustic insulation panel. The exposed, perforated and corrugated surface is designed to allow unwanted sound vibrations to be diffused and absorbed by the insulation inside. Proper positioning of VPA panels can greatly reduce the reverberation effect of sound waves, thereby controlling and even improving the acoustics of an auditorium, amphitheatre or any large room.

They can be installed on walls or ceilings, and several types of attachment are available. It is also possible to design a fastening system specific to the chosen application, should the standard types of attachment not be suitable.
